Product Specifications
|
Component |
Specification |
Notes |
|
Top Control Bar |
16mm Solid Round Steel |
Ensures high structural rigidity for row-wide locking and unlocking; highly resistant to deformation. |
|
Main Frame Base Tube |
50x50x3mm Square Tube |
Thickened base frame provides a rock-solid foundation for the entire assembly. |
|
Upright / Pivot Tubes |
Φ42mm x 2.5mm Round Tube |
Constructed from high-strength steel for smooth rotation and minimal friction on the animal's neck. |
|
Locking Plate |
4mm Steel Plate |
Core stress points utilize 4mm reinforced plating for superior impact resistance and secure locking. |
|
Standard Spacing |
714mm (Center-to-Center) |
Ergonomically designed width suitable for adult dairy or beef cattle to ensure feeding comfort. |
Cow Headlock Features
Constructed from high-quality Q235 steel, fully hot-dip galvanized after fabrication, with a ≥42 μm coating for long-lasting corrosion resistance
Precision fabrication and welding ensure a robust structure with a clean, durable finish
Customizable design to suit different cattle sizes and housing dimensions
